AP-207

The HPE JX952A Aruba 207 Series Access Points deliver high-performance 802.11ac for medium density enterprise environments, such as schools, retail branches, warehouses, hotels and enterprise offices, where the environment is cost-sensitive. It has a compact size which delivers a maximum concurrent data rate of 867Mbps in the 5GHz band and 400 Mbps in the 2.4GHz band (for an aggregate peak data rate of 1.3Gbps). With the integrated Bluetooth Aruba Beacon, it provides advanced location and indoor wayfinding, and proximity-based push notification services while simplifying the remote management of battery-powered Aruba Beacons.

QUICK SPECIFICATIONS

• Product Name: AP-207 Wireless Access Point
• Product Type: Wireless Access Point
• Form Factor: In-ceiling – indoor
• Ports: One 10/100/1000BASE-T Ethernet network interface (RJ-45)
• Connectivity, standard: IEEE 802.11 a/b/g/n/ac
• Power Consumption: Maximum (worst-case) power consumption: 12.3W (PoE) or 10.1W (DC)
• Wi-Fi antenna: Two integrated dual-band down tilt omni-directional antennas for 2×2 MIMO with maximum antenna gain of 3.4dBi in 2.4GHz and 6.6dBi in 5GHz.
• Radio coverage: Indoor, dual radio, 5GHz 802.11ac 2×2 MIMO and 2.4GHz 802.11n 2×2 MIMO
• Minimum dimensions ( H x W x D): 150 x 150 x 40 mm
• Weight: 380 g
