JPSU-550-C-AC-AFO
JPSU-550-C-AC-AFO
Original price was: $500.00.$320.00Current price is: $320.00.
Power Juniper JPSU-550-C-AC-AFO EX4400 550W AC power supply (power cord ordered separately cần) (front-to-back airflow) is for devices Switch Juniper : EX4400-48T, EX4400-24T , EX4400-48F
JPSU-550-C-AC-AFO Technical Specifications
Juniper 550W AC power supply
Dimensions & Weight / Weight 800 g
General / Subcategory Power supplies
Header / Brand Juniper Networks
Miscellaneous / Product Color Black
Networking / Type Switch
Packaged Quantity 1
Power Device / Form Factor Plug-in module
Power Device / Power Supply Compatibility Network hardware
Power Device / Voltage Required AC 100-120/200-240 V
Product Type Power supply – hot-plug / redundant
Dimensions & Weight
Weight 800 g
General
Device Type Power supply – hot-plug / redundant – plug-in module
Miscellaneous
Features Front to rear airflow
Power Device
Input Voltage AC 100-120/200-240 V
Power Capacity 550 Watt
JPSU-550-C-AC-AFO Specification
JPSU-550-C-AC-AFO Specifications |
|
| Brand | Juniper |
| Model | JPSU-550-C-AC-AFO |
| Power Capacity | 550W |
| Input Voltage Range | 90-264 VAC |
| Input Frequency | 50-60 Hz |
| Input Current | Max. 8A |
| Output Voltage | 12V DC |
| Operating Temperature | 0°C to 45°C |
| Storage Temperature | -40°C to 70°C |
| Relative Humidity | 5% to 95% (non-condensing) |
| Cooling | Airflow Out (AFO) |
| Compliance | RoHS, WEEE |
| Certifications | CE, UL, TUV, FCC |
| Mounting Type | Hot-swappable |
| Compatibility | Juniper EX4400 Switches |
| Dimensions (H x W x D) | 1.59 x 7.28 x 7.69 inches |
| MTBF (Mean Time Between Failures) | Over 1,500,000 hours |
| Connector Type | IEC 320-C14 |
| Protection Features | Over Current, Over Voltage, Over Temperature |
| Indicator LEDs | AC OK, DC OK, Fan OK |
| Warranty | 1 Year Limited |
Product Features
- ● High efficiency 550W power output
- ● Designed for Juniper EX4400 series switches
- ● Compact form factor for easy installation
- ● Advanced cooling technology
- ● Universal AC input range of 100-240V
Product Applications
- ● Enterprise network infrastructure requiring reliable power supplies
- ● Data centers using Juniper EX4400 series switches
- ● Campus networks demanding high power efficiency and compact units
Supported Options
| Accessory | Model |
| Power Cable | JPC-C13-C14-2M |
| Mounting Bracket | EX4400-BRKT-MNT |
| Cooling Fan | JPC-FAN-AFO |
Compare to Similar Products
| Model | Differentiating Factor |
| JPSU-650-AC-AFO | 650W Power Capacity |
| JPSU-350-DC-AFO | 350W Power, DC Input |
| JPSU-750-AC-AFO | 750W Power Capacity |
