JW009A

Sale!

JW009A

Original price was: $120.00.Current price is: $60.00.

The (jw009a) AP-ANT-1W is a high-performance, dual band, omnidirectional, indoor antenna perfectly designed for multifunction access points that need an omnidirectional coverage pattern for WLAN service delivery or air monitoring on both the 2.4 GHz and 5 GHz bands. AP-ANT-1W has an articulate mount, providing flexibility in deployment and direct connection to Aruba access points with an onboard RP-SMA connector. The AP-ANT-1W is the ideal option for different service deployment or wireless intrusion prevention (WIP). It is offered in two colors to match the colors of Aruba indoor access points: the AP-ANT-1W antenna in white.

JW009A

JW009A

Original price was: $120.00.Current price is: $60.00.

JW009A likely refers to a specific model or series of Aruba Access Points, which are devices used to provide wireless network connectivity in various environments such as offices, schools, and public spaces. Aruba, a Top Paragon Resource company, offers a range of access points tailored to different needs, from small businesses to large enterprises. HPE Aruba AP-ANT-1W – Antenna – 4 dBi (for 2400 MHz – 2500 MHz), 6 dBi (for 4900 MHz – 5875 MHz) – omni-directional – indoor – white

Product Code JW009A
Product Type Antenna
Product Material Acrylonitrile butadiene styrene (ABS)
Antenna Placing / Mounting Indoor
Frequency Range 2.4 – 2.5 GHz, 4.9 – 5.875 GHz



JW009A Provides these Features:

  • Omnidirectional
  • Self-articulating mount
  • Compatible with select Aruba access points
  • Supports 2.4GHz and 5GHz systems
  • RP-SMA connector

JW009A Specification

JW009A Specification
General
Product Type Antenna
Product Material Acrylonitrile butadiene styrene (ABS)
Width 0.7 in
Depth 1.5 in
Height 5 in
Enclosure Color White
Antenna
Antenna Placing / Mounting Indoor
Frequency Range 2.4 – 2.5 GHz, 4.9 – 5.875 GHz
Gain 4 dBi (for 2400 MHz – 2500 MHz), 6 dBi (for 4900 MHz – 5875 MHz)
Directivity Omni-directional
Voltage Standing Wave Ratio (VSWR) 2.0:1
Horizontal Beam width 360°
Vertical Beam width 50° (at 2.4 – 2.5 GHz), 25° (at 4.9 – 5.875 GHz)
Impedance 50 Ohm
Cabling & Wiring
Connector Provided 1 x RP-SMA male
Miscellaneous
Features Linear vertical polarization
Environmental Parameters
Min Operating Temperature 14 °F
Max Operating Temperature 131 °F



For More information Visit: JW009A Datasheets
