SFP-10G-LR
SFP-10G-LR
$165.00
The Cisco SFP-10G-LR module is a single-mode 10G fibre optical transceiver; the Cisco 10G Base-LR Module supports a link length of 10 kilometers on standard single-mode fibre (SMF, G.652); and Solid-Optics’ SFP-10G-LR SFP Plus optical transceiver provides up to 10 kilometers on standard single-mode fibre.
The Features
☆ Industry’s smallest 10G form factor for greatest density per chassis
☆ Hot-swappable input/output device that plugs into an Ethernet SFP+ port of a Cisco switch
☆ Supports “pay-as-you-populate” model for investment protection and ease of technology migration
☆ Digital optical monitoring capability for strong diagnostic capabilities
☆ Optical interoperability with 10GBASE XENPAK, 10GBASE X2, and 10GBASE XFP interfaces on the same link
☆ Cisco quality identification (ID) feature enables a Cisco platform to identify whether the module is certified and tested by Cisco
The Cisco 10G Base-LR is a small yet powerful transceiver, swift and steady in delivering 10 Gigabit links. The module supports single-mode fiber, carrying data as far as 10 kilometers. A must-have tool for tech lovers aiming to boost their networks. Be it for personal or professional use, the SFP-10G-LR guarantees undisturbed communication. Simply plug it in, enjoy energy-saving features, and experience far-reaching efficiency.
Why Choose the SFP-10G-LR for Long-Range Networking?
Technology lovers who require dependable, speedy information exchange between distant places make use of the Cisco 10G Base-LR. The 10 Gigabit support of this device is compatible with that of single mode fiber. The maximum distance its range can reach is 10 kilometers. Its small size makes it easy to install no matter if you are configuring a home network or upgrading a business. In addition, its power-saving construction reduces power intake, hence allowing fast and reliable connections while still being mindful of the exorbitantly rising power bills. This is why Cisco 10G Base-LR suits better in long-distance networks:
- Long-range performance: single-mode fiber can connect up to 10 kilometers away.
- 10 Gigabit speeds: Provides fast and stable data transmission.
- Ability to diagnose: digital optical monitoring for good ability to diagnose
- Energy-efficient: Minimizes power usage while delivering top performance.
- Port’s switch: A Cisco switch’s Ethernet SFP+ port can be used as an input or output device at any time by plugging in a switch port device.
The best way to connect data centers over long distances is with the SFP-10G-LR. Also, make the network work better in your home.
What Purpose is The Single-Mode 10G Fiber Optical Transceiver Used For?
Cisco 10G Base-LR provides a great way to transfer information between different network appliances over long distances at a bandwidth of about 10 Gb/s.
What Steps Does the SFP-10G-LR Follow in Enhancing Network Functionality?
It connects quickly and steadily for far-off areas causing an even flow in your net. Your network will run smoothly as a result due to rapid and reliable connections.
Specification
| Compatible OEM Part Number | SFP-10G-LR-X | Optcore Part Number | OSP10G-3110DTR-CSC |
| Form Factor | SFP+ | Data Rate | 10Gb/s |
| Wavelength | 1310 nm | Fiber Type | SMF |
| Max Distance | 10 km | Optical Components | DFB/PIN |
| Transmitter Power | -6 ~ 0 dBm | Extinction ratio | > 3.5 dB |
| Receiver Sensitivity | < -14.4 dBm | Receiver Overload | > 0.5 dBm |
| Connector | LC Duplex | Digital Diagnostic Monitoring | Yes |
| Environment | Operating: -40°C to 85°C Storage: -40°C to 85°C |
Weight | 0.03 kg |
| Application | 10GBASE-LR/10GBASE-LW Ethernet10G Fiber Channel
10GbE Data Center Switches and Routers |
Compliance | IEC/EN 61000-4-2,IEC-60825 FDA 21CFR 1040.10 and 1040.11 RoHS |
SFP-10G-LR Can be Supported in a Switch SFP Slot.
| Cisco SFP+ | Wavelength (nm) | Cable Type | Core Size (Microns) | Modal Bandwidth (MHz/km) | Cable Distance |
| SFP-10G-SR | 850 | MMF | 62.5
62.5 50.0 50.0 50.0 50.0 |
160 (FDDI)
200 (OM1) 400 500 (OM2) 2000 (OM3) 4700 (OM4) |
26m
33m 66m 82m 300m 400m |
| SFP-10G-LR | 1310 | SMF | G.652 | – | 10km |
SFP 10G LR Specification
| SFP 10G LR Specifications | |
| Product Model | Cisco SFP-10G-LR |
| Data Rate | 10 Gbps |
| Form Factor | SFP+ |
| Wavelength | 1310nm |
| Connector | Duplex LC |
| Transmitter Type | DFB |
| Power budget | 6.2dB |
| Power Consumption | ≤1W |
| Commercial Temperature Range | 0 to 70°C (32 to 158°F) |
| Max Data Rate | 10.3125Gbps |
| Media | SMF |
Questions & Answers
What are the key features of the SFP-10G-LR module?
The SFP-10G-LR module features a compact form factor, low power consumption, and amazing optical performance for reliable data transmission.
Can the SFP 10G LR module be used with Cisco switches and routers?
Yes, the SFP 10G LR module is compatible.
Is there a warranty included with the SFP-10G-LR module?
Yes, the SFP-10G-LR module are available with a standard Cisco warranty. Visit Datasheet
What accessories are included with the SFP-10G-LR module?
The SFP 10G LR module normally includes a dust plug and a user guide for easy installation and maintenance.
