FG-TRAN-QSFP+SR-BIDI
FG-TRAN-QSFP+SR-BIDI
Original price was: $1,500.00.$1,330.00Current price is: $1,330.00.
Fortinet Compatible FG-TRAN-QSFP+SR-BIDI QSFP 40GBASE-SR-BiDi Module is based on our product BIDI-40G-QSFP-150. When You will order it will be encoded with Fortinet code and it will be labeled with part number: BIDI-40G-QSFP-150-FO, where FO means Fortinet Compatible. Above You can download datasheet of our BIDI-40G-QSFP-150 product.
FG-TRAN-QSFP+SR-BIDI
Original price was: $1,500.00.$1,330.00Current price is: $1,330.00.
| Media Type: | Multi-Mode Fiber (MMF) |
|---|---|
| Maximum Distance: | 150m |
| Transceiver Type: | QSFP |
| TX Wavelength: | Ch1:850nm; Ch2:900nm |
| RX Wavelength: | Ch1:900nm; Ch2:850nm |
| Minimum Optical Budget: | 2 dB |
| Supported Data Rate: | 39.81 – 44.8 Gbps |
| Supported Applications: | 40G Ethernet (41.25Gbps), STM-256 (39.81 Gbps), OTU3 (43.01Gbps), OTU3e2 (44.58Gbps) |
| DDM/DOM: | Supported |
| Temperature Range: | Standard 0°-70°C |
| Connectors: | Double LC |
| Tx Wavelength Bandwidth: | 36nm (Ch1:832-868nm and Ch2: 882-918nm) |
| Rx Wavelength Bandwidth: | 36nm (Ch1:882-918nm and Ch2:832-868nm) |
| Minimum Transmitting Power: | Each Lane -4 dB |
| Maximum Transmitting Power: | Each Lane 5 dB |
| Receiver Sensitivity: | Each Lane -6 dB |
| Receiver Overload: | Each Lane 3 dB |
| Transmitter Type: | VSCEL Laser |
| Receiver Type: | PIN photodiode |
| Power: | +3.3V single power supply |
| Chipset: | MAXIM, MINDSPEED, SEMTECH, UX |
| Compliance: | 40GBASE-SR-BiDi, CE, Class 1 FDA and IEC60825-1 Laser Safety Compliant, INF-8438i, QSFP+ MSA, RoHS, SFF-8436 |
